OSRAM S26A - R7S RX7s and RSC Lamp Holder Ceramic Socket

OSRAM Lampholder for double ended R7S, RX7S and RSC bulbs - S26A AWG16 SF2 (URC) 18in Lead Length
This socket is a front-mount socket. For the back mount socket please search for sku 69012, or see related items below.
This item is the same as BulbAmerica R7S-FM-SOCKET or Ushio SKU # 1000117 (the wire on the Ushio is shorter).

This lamp holder is for bulbs with R7s and RX7s base, like:
- 150/25T4, - FCM, - FFM, - DWT, - FDA, - FHM, - DXW, - FDB, - 64579 115, -120V, - EHP, - FDN, - FFT, - EHR, - FER, - 6.6A/200T5/CL/64380, - EJG, - FEX/230, - 6.6A/45T3/CL/64315, - FAD, - FEX/240, - 1600T3Q/IR/7 240V, - FAL, - FEY, - 2500T3Q/IR/7 480V, - FCB, - FFJ, - 500T3Q/IR/7 120V
- Brand Name: OSRAM
- R7s, RX7s Recessed Single Contact (RSC) socket
- Wire Gauge: 16 AWG
- Maximum Voltage (V) 600
- Maximum Wattage (W) 3000

Manufacturer	OSRAM
Part Number	69011
UPC	046135690112
EAN	4008321388674
Application	Lamp Holder
Base	R7s Recessed Single Contact, RX7S RSC
Color	Black
Contact Material	Silver Plated Copper
Operation Temperature (F)	662
Type	S26A
Voltage (V)	600
Wire Guage/Type	AWG16 SF2
Length (in)	18.00

Manual:

OSRAM 69011 S26A 18IN/16GA/ULSF2
