HPL 575w 115V LL USHIO HPL-575/115X 575 watt Long Life halogen lamp bulb

Ushio HPL-575/115X+, JS115V-575WX, HPL 575Watt 115V Long Life tungsten halogen, HPL Lamp.

The High performance Ushio 1000671 HPL-575/115X+, JS115V-575WX, 2000 Hour lamp has been redesigned to be the most powerful HPL ever. It's ultra-compact filament geometry now improves the optional efficiency of your ETC Source Four fixtures to produce up to 20% more fixture lumens. That's up to 20% more light from the same fixture as compared to the old lamp design.

Features:
- Abbreviation Name: HPL-575/115X+, JS115V-575WX, 2000 Hour
- Description 2: 575W 115V
- Base: G9.5 2-Pin w/ Heat Sink
- Bulb Type: Halogen Bulbs
- Color Rendering Index (CRI): 100
- Color Temperature (K): 3050K
- Diameter (in): 0.72
- Filament: 4-C8
- Lamp Finish: Clear
- Luminous Flux (LM): 12360
- Maximum Overall Length (in): 4.09
- Rated Life (Hours): 2000
- Shape: T6
- Voltage: 115V
- Wattage: 575W

Abbreviation Name	HPL-575/115X+, JS115V-575WX, 2000 Hour
Description 2	575W 115V
Base	G9.5 2-Pin w/ Heat Sink
Bulb Type	Halogen Bulbs
Color Rendering Index (CRI)	100
Color Temperature (K)	3050K
Diameter (in)	0.72
Filament	4-C8
Lamp Finish	Clear
Luminous Flux (LM)	12360
Maximum Overall Length (in)	4.09
Rated Life (Hours)	2000
Shape	T6
Voltage	115V
Wattage	575W

Manual:

Ushio 1000671 HPL-575/115X+
HPL Cross Reference

The HPL575/115 bulbs is used in following equipment:

- ETC Source Four
- ETC Source Four 230 V
- ETC Source Four Jr
- ETC Source Four junior 230 V
- ETC Source Four Par & Parnel
- ETC Source Four Par 575
- ETC Source Four Zoom
